H13

WELDING WIRES FOR HARDFACING

Classifications

Werkstoff 1.2344
AISI H13

Process

GAS MIG TIG A.S.

Applications

Welding wire for hot work tool steels with excellent hot tensile properties, high hot wear resistance. Heat checking resistance. Used in particular to repair mandrels, punches, dies, cylinder crushers, screws, hammers, pneumatic hammers, etc.

Base materials to be welded

X40CrMoV5-1 ; H13, BH 13 ; SCPH 62, STD 62

Dimensions

MIG (mm)

0,80 - 0,90 - 1,00 - 1,14 - 1,20 - 1,40 - 1,60

TIG (mm)

1,20 - 1,60 - 2,00 - 2,40 - 3,00 - 3,20 - 4,00

Welding process

Protection

MIG: M21 Mixture and similar / TIG: I1 (Argon)

Current and polarity

MIG: DC+ / TIG: DC-

Pre Heating temperature

340 - 370Â° C

Average Chemical analysis

Si%

Mn%

Cu%

Cr%

Mo%

0,40

1,00

0,40

< 0,020

< 0,35

5,20

1,40

1,00

The copper value include the surface coating

Typical mechanical properties of all-weld metal

Hardness

HRC

54 - 60

The mechanical properties are approximate and may range on the basis of the Heat, shielding gas, welding parameters and other factors

Approvals

Contact ITALFIL

Fields of application

Maintenance and repair
